Standard RDHx

立即諮詢

The ideal energy-efficient cooling solution to help data center customers handle increased load output and for high-density server/storage deployments.
Quickly reduce PUE under 1.3.
The maximum antipyretic capacity of a single cabinet can reach more than 30kW.
No need to install fans, zero energy consumption, zero noise
It can be connected to the cooling water provided by the client or used in conjunction with a dedicated cooler

M/N	RDHx-TD38
P/N	TD38-642
Cabinet Size	42U，600mm W
RDHx Size(H x W x D)	1950 x 600 x 130mm
Net weight for RDHx	58kg
Max cooling capacity*Note2	39.5kW
Min cooling capacity*Note3	26.5kW
Coolent	Coolant THC-00
Coolent Capacity	10.0L (2.7 Gal)
Clloent Flow Rate	up to 56.8 LPM (15 GPM)
Temperature@ inlet	Above dew point
Max Working pressure	690 kPa (100 psl)
Air flow pressure drop	0.17 inH2O @ 4000 CFM
Liquod Flow Pressure Drop *Note4	54.5 kPa (7.9 psl)
Radiator type	Copper Tube, Aluminum Fin
Connection	ISO 7241-1 Series B self sealing Quick disconnects
Connector Material	Brass or 304 Stainless Steel
Connector Type	3/4″ Quick disconnects
Coolent-In Location	Top or Bottom Feed
Noise	0 dBA

M/N	RDHx-TD28
P/N	TD28-642	TD28-842
Cabinet Size	42U，600mm W	42U，800mm W
RDHx Size(H x W x D)	1950 x 600 x 130mm	1950 x 800 x 130mm
Net weight for RDHx	55kg	57kg
Max cooling capacity*Note2	29.5kW	34.2kW
Min cooling capacity*Note3	20.2kW	22.6kW
Coolent	Coolant THC-00	Coolant THC-00
Coolent Capacity	10.0L (2.7 Gal)	10.8L (2.85 Gal)
Clloent Flow Rate	up to 56.8 LPM (15 GPM)	up to 56.8 LPM (15 GPM)
Temperature@ inlet	Above dew point	Above dew point
Max Working pressure	690 kPa (100 psl)	690 kPa (100 psl)
Air flow pressure drop	0.142 inH2O @ 4000 CFM	0.1 inH2O @ 4000 CFM
Liquod Flow Pressure Drop *Note4	54.5 kPa (7.9 psl)	57.3 kPa (8.3 psl)
Radiator type	Copper Tube, Aluminum Fin	Copper Tube, Aluminum Fin
Connection	ISO 7241-1 Series B self sealing Quick disconnects	ISO 7241-1 Series B self sealing Quick disconnects
Connector Material	Brass or 304 Stainless Steel	Brass or 304 Stainless Steel
Connector Type	3/4″ Quick disconnects	3/4″ Quick disconnects
Coolent-In Location	Top or Bottom Feed	Top or Bottom Feed
Noise	0 dBA	0 dBA

M/N	RDHx-TD18
P/N	TD18-642	TD18-842	TD18-647	TD18-652
Cabinet Size	42U，600mm W	42U，800mm W	45~48U，600mm W	52U，600mm W
RDHx Size(H x W x D)	1950 x 600 x 117mm	1950 x 800 x 117mm	2160 x 600 x 117mm	2360 x 600 x 117mm
Net weight for RDHx	29.6kg	34kg	35kg	40.4kg
Max cooling capacity*Note2	21.6kW	30.6kW	23.2kW	25kW
Min cooling capacity*Note3	14.6kW	22.2kW	15.6kW	16.6kW
Coolent	Coolant THC-00	Coolant THC-00	Coolant THC-00	Coolant THC-00
Coolent Capacity	5.7L (1.5 Gal)	7.3L (1.9 Gal)	5.9L (1.56 Gal)	6.1L (1.6 Gal)
Clloent Flow Rate	up to 45 LPM (12 GPM)	up to 45 LPM (12 GPM)	up to 45 LPM (12 GPM)	up to 45 LPM (12 GPM)
Temperature@ inlet	Above dew point	Above dew point	Above dew point	Above dew point
Max Working pressure	690 kPa (100 psl)	690 kPa (100 psl)	690 kPa (100 psl)	690 kPa (100 psl)
Air flow pressure drop	0.075 inH2O @ 4000 CFM	0.075 inH2O @ 4000 CFM	0.075 inH2O @ 4000 CFM	0.075 inH2O @ 4000 CFM
Liquod Flow Pressure Drop *Note4	51.9 kPa (7.52 psl)	54.5 kPa (7.9 psl)	49.5 kPa (7.18 psl)	47.1 kPa (6.83 psl)
Radiator type	Copper Tube, Aluminum Fin	Copper Tube, Aluminum Fin	Copper Tube, Aluminum Fin	Copper Tube, Aluminum Fin
Connection	ISO 7241-1 Series B self sealing Quick disconnects	ISO 7241-1 Series B self sealing Quick disconnects	ISO 7241-1 Series B self sealing Quick disconnects	ISO 7241-1 Series B self sealing Quick disconnects
Connector Material	Brass or 304 Stainless Steel	Brass or 304 Stainless Steel	Brass or 304 Stainless Steel	Brass or 304 Stainless Steel
Connector Type	3/4″ Quick disconnects	3/4″ Quick disconnects	3/4″ Quick disconnects	3/4″ Quick disconnects
Coolent-In Location	Top or Bottom Feed	Top or Bottom Feed	Top or Bottom Feed	Top or Bottom Feed
Noise	0 dBA	0 dBA	0 dBA	0 dBA

Note:

The above evaluation of cooling capacity is based on the conditions of ASHRAE. The inlet air volume of the cabinet is taken @100 CFM/kW, the ambient humidity is 50%, and the inlet water temperature of the back door is set to 18 °C
The evaluation of the maximum cooling capacity is based on the evaluation data at an allowable ambient temperature of 27 °C
The evaluation of the minimum cooling capacity is based on the evaluation data at an allowable ambient temperature of 25 °C
The flow rate of the 30kW back door data test is set to 56.8 LPM, and the flow rate of the 20kW back door data test is set to 45 LPM
